Advanced sheetpress, ideal for workshops, fablabs and small enterprise
The press mechanism is electronical (stepper motor with toggle clamp)
Specifications
Type
Sheetpress
Version
0.1
Weight
80 - 120 Kg
Voltage
380V
Status
Development
Sheet Size
60 x 60 cm
Plate Size
70 x 70 cm
Pressure
2-5 tons, depending on the sheet thickness
Input Flake Size
Medium, Small
Gearbox ratio
1:15
Heaters
300 Watt x 32 (10kW)
Options
- Precision Temperature controllers (+/- 1 DegC tolerance)
- Loader table
- Touchscreen for storing different temperature profiles
Dimensions
Parts
| Part Nr. | Description | Configuration | |
|---|---|---|---|
| 1 | Fume Exhaust Pipe | Optional | |
| 2 | Fume Hood | Integrated fan | |
| 3 | Doors | Spring loaded | |
| 4 | Loader rollers | Optional | |
| 5 | Sheet thickness adjuster | 5cm | |
| 6 | Heatplate | 10mm 5038 precision Aluminium | |
| 7 | Lift Links |
